16-bit brightness control resolution
Brightness control using two DMX channels allows to achieve an outstanding resolution – 65536 levels of brightness! Thanks to this the device is ideally suited for professional theater installations, stage performances and broadcast TV. The ability to control the brightness in the full range allows to achieve excellent results of smooth changes and enables the precise setting of the desired color from the basic colors.
Brightness control curves
The ability to choose different brightness control curves allows to achieve the effect of a very smooth transition between different levels of brightness with a standard 8-bit control (single DIMMER fader). By choosing curves such as “Log” or “S-Curve” user can achieve more natural, smooth dimming, which is more visible at low DMX values. Additionally, this feature opens up new possibilities in color mixing at low magnitudes.
Dim delay – bulb simulation
Delayed LEDs reaction to the DIMMER fader changes causes even greater smoothing of brightness changes – even with 8-bit controll (single DIMMER fader)! By enabling this feature and selecting one of the specially designed characteristic curves (eg. “S-Curve”), you can obtain a perfect dimming effect with no jump between levels!
