RME HDSPe MADI PCI Express card NOB

128 channel MADI PCI Express card

Ask about this item

€ 529 excl tax

Price is excluding VAT What's this?


1 Available


Description

The HDSPe MADI is RME’s both inexpensive and outstanding PCI Express card with MADI interface. HDSPe MADI is based on the award-winning HDSP MADI card, and represents the new top model of this world-wide successful card line.


SKU: 11109 Category: Tag: Brand: RMEMPN: HDSPeEAN: 7333293111096Condition: NewCondition Description: New Open BoxWarranty: 1 monthPackaging: Original boxTariff (HS-Code): 8543 70 90 99Location: Sweden

Share:

  • 1-Lane PCI Express Endpoint device (no PCI Express to PCI Bridge), revision 1.1.
  • 2.5 Gbps line speed
  • Packet-based full-duplex communication (up to 500 MB/s transfer rate)
  • All settings changeable in real-time
  • Automatic and intelligent master/slave clock control
  • Sync sources: MADI coaxial, MADI optical, word clock, internal
  • Varipitch: by input signal or word clock
  • Sample rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, variable (Sync/word clock)
  • Sample rate range: MADI: 32 kHz – 96 kHz, word clock: 27 kHz – 200 kHz
  • Jitter: < 1 ns, internal and all inputs
  • Jitter sensitivity: PLL operates even at 100 ns Jitter without problems
  • Comes with DIGICheck: the ultimate measurement, analysis and test tool
  • Input MADI optical, MADI coaxial (BNC), 2 x MIDI, word clock (BNC)
  • Output MADI optical, MADI coaxial (BNC), 2 x MIDI, word clock (BNC), stereo analog line/phones
  • Input word clock: BNC, Signal Adaptation Circuit (functional from 1.2 Vpp input signal), switchable termination
  • Output word clock: BNC, low-impedance driver stage, 4 Vpp into 75 Ohms, short-circuit-proof
  • MIDI input and output: via four 5-pin DIN jacks
