Graphic equalisers are found in just about every sound application, from room contouring to feedback control and general audio sweetening.
All these effects can be easily made without disturbing the critical fader settings already made.
Chassis 3U rack spaces
Input Connectors XLR, TRS, Combicon (2 each)
Output Connectors XLR, TRS, Combicon (2 each)
EQ Bands 30 per channel (60 total)
Filter Width (Q) Constant-Q
EQ Gain +/- 15dB per band, plus – inf to +10dB overall
Metering 8-segment LED per channel
Bypass Switch yes
High-Pass Filter Sweepable, flat to 250Hz
Low Frequency Contour Smooth shelving filter, +/- 6dB at 50Hz
High Frequency Contour Smooth shelving filter, +/- 6dB at 14kHz
